High power destiny
Possibility to be used assembled in open air
High working temperatures
Fast warm up
High power destiny
Possibility to be used assembled in open air
High working temperatures
Fast warm up
Max element temp. | 800C |
Dielectric strength at 20C as per ASTM KV/mm | >25 |
Thwemal conductivity at 100C W/(m.k) | 0.30 |
Moisture absorption as per ASTM D-570-63. (24h immersion at 23C) | <1% |
Constant of dielectricity at 25C, 50Hz | 4-5.5 |
Max.element width | 900mm |
Power density | 10W/cm²(depending on application) |
Resistance tolerance | As standard, ±10% of nominal. Tolerance down to ±2% available |
Rated voltage | Up to 1000V AC/DC single or 3 phase |
Other | Thickness min. 0.1mm |
Max element temp. | 800C |
Dielectric strength at 20C as per ASTM KV/mm | >25 |
Thwemal conductivity at 100C W/(m.k) | 0.30 |
Moisture absorption as per ASTM D-570-63. (24h immersion at 23C) | <1% |
Constant of dielectricity at 25C, 50Hz | 4-5.5 |
Max.element width | 900mm |
Power density | 10W/cm²(depending on application) |
Resistance tolerance | As standard, ±10% of nominal. Tolerance down to ±2% available |
Rated voltage | Up to 1000V AC/DC single or 3 phase |
Other | Thickness min. 0.1mm |
Name | Model | Specifications |
Leading line | Teflon wire UL1332 | 300V，26AWG-10AWG |
Teflon wire UL1330 | 600V，26AWG-10AWG | |
PI line | 300V，30AWG-20AWG | |
Silicone rubber line | 300V，0.5mm2-2.5mm2 | |
Glass fiber line | 300V，0.5mm2-4mm2 | |
3M glue | 468/467 | working temperature ≤ 149℃ |
966/9079 | working temperature ≤ 179℃ | |
9888T | working temperature ≤ 119℃ | |
Controller | OT1 | 0-200°C JPt 100Ω sensor |
OT3 | 0-300°C PID controller | |
OT4. OT5 | 100ºC | |
EGO | 0-40ºC 30-110ºC 60-200ºC | |
Thermo | 50ºC 70ºC 100ºC 120ºC 150ºC |
Name | Model | Specifications |
Leading line | Teflon wire UL1332 | 300V，26AWG-10AWG |
Teflon wire UL1330 | 600V，26AWG-10AWG | |
PI line | 300V，30AWG-20AWG | |
Silicone rubber line | 300V，0.5mm2-2.5mm2 | |
Glass fiber line | 300V，0.5mm2-4mm2 | |
3M glue | 468/467 | working temperature ≤ 149℃ |
966/9079 | working temperature ≤ 179℃ | |
9888T | working temperature ≤ 119℃ | |
Controller | OT1 | 0-200°C JPt 100Ω sensor |
OT3 | 0-300°C PID controller | |
OT4. OT5 | 100ºC | |
EGO | 0-40ºC 30-110ºC 60-200ºC | |
Thermo | 50ºC 70ºC 100ºC 120ºC 150ºC |
Packing, strapping and sealing equipment
food service applicances
DNA analyse
semiconductor industry
radiators, heating panels
Packing, strapping and sealing equipment
food service applicances
DNA analyse
semiconductor industry
radiators, heating panels
